Reduction Cum Pinion Gear Box
Technical Specification
A reduction gear box is used to reduce an input speed to a slower output speed and more output torque. It is a wheel work consisting of a connected set of rotating gears by which power is transmitted or motion or torque is changed. We can manufacture and supply stage, double stage or multistage gear boxes having single outputs as required.
We at “THE KAMAL ENGINEEIRING” provide Reduction Cum Pinion Gear Box as per the following configuration.
| STRUCTURE MATERIAL | Casing / Housing /Steel Fabricated |
| GEAR MATERIAL | Forged and Forged blank EN-9, EN-19, EN-24 Steel |
| GEAR TYPE | Spur, Single & Double Helical Gears up to 2500mm Día |
| LOAD RANGE | Normal Input From 200 HP up to 2000 HP. Drives |
| MAXIMUM PEAK LOAD | 6000 HP. |
| SIZE RANGE | 150mm PCD up to 750mm PCD |
| SPEED | 50 RPM to 1500 RPM |
| ALL SHAFTS MATERIAL | Forged Class – IV |
| ANCHOR / FOUNDATION BOLTS | Carban Steel |
