Universal Coupling and Spindles
Technical Specification
The universal couplings are provided with a purpose to eliminate any misalignment or
angular inclination at drive side so that the cluster of rolls forms properly
aligned, right angled matrix with respect to pass line. To nullify the effect of
vibrations causing damping effect on tolerance of the rolling stock, necessary
provision for spindle carrier is carried out.
UNIVERSAL COUPLINGS
We at “THE KAMAL ENGINEERING” provide Universal Couplings as per the
following configuration.
|
TYPE |
PALM END TYPE |
|
SPINDLE MATERIAL |
EN-9 |
|
MATERIAL OF UNIVERSAL COUPLING HEAD |
EN-9 |
|
MATERIAL OF PADS FOR UNIVERSAL COUPLINGS |
Nylon |
Construction of Universal Coupling & Spindle:
1.) Spindles and couplings are required to connect output shafts of Pinion Stand to rolls of mill stands.
2.) Each set will consist of two couplings head assemblies and one spindle.
UNIVERSAL SPINDLES
1.) Provision on the spindles for their support has to be provided.
2.) Each set of grease bath type universal couplings and spindles shall have one number spindle and two numbers couplings heads.
3.) The coupling head assembly shall be fitted with sleeves and all fitments including non-ferrous slipper pads Send Enquiry
